Cocoa Bean Seed Vibrator Separator/vibrating Screen Sieve With Magnetic Separator/Vibrating Sieve Separator/ Sorter
Cocoa Bean Seed Vibrator Separator/vibrating Screen Sieve With Magnetic Separator/Vibrating Sieve Separator/ Sorter produced and sold by Xinxiang Dayong vibration equipment Co., Ltd. is dedicated to screening cocoa seeds.Bracket: It consists of four pillars and two channel steels, which support the screen box. When installing, the pillars must be perpendicular to the ground, and the channel steels below the two pillars should be parallel to each other.
Material: stainless steel, carbon steel
Model: DZSF515, DZSF520, DZSF525, DZSF1020, DZSF1025, DZSF1030
Price: $1000-$1500
When the Cocoa Bean Seed Vibrator Separator/vibrating Screen Sieve With Magnetic Separator/Vibrating Sieve Separator/ Sorter is working, the two motors rotate in the opposite direction synchronously, so that the exciter generates a reverse exciting force, which forces the screen box to drive the screen to do longitudinal movement, so that the material on it is periodically thrown forward by the exciting force for a range. In this way, the material screening operation is completed. When the two vibrating motors rotate synchronously and in opposite directions, the exciting force generated by the eccentric blocks cancels each other in the direction parallel to the motor axis, and superimposes a resultant force in the direction perpendicular to the motor axis. Therefore, the motion trajectory of the screen machine is a straight line. The two motor shafts have an inclination angle in the vertical direction relative to the screen surface. Under the combined force of the exciting force and the self-gravity of the material, the material is thrown on the screen surface to jump or move forward in a straight line, so as to achieve the purpose of screening and grading the material. Linear vibrating screen is commonly used in: ferrosilicon, sand, pepper particles, wheat peel, pumpkin seeds, silicon powder, sugar, traditional Chinese medicine, betel nut, silicon carbide powder, stone, activated carbon particles, soil, sand, millet, pulp, shells, cooked Sesame, machine-made sand, chrysanthemum, quartz sand, construction waste, coke powder, plastic particles, river sand and other materials. Vibrating machine/separator vibrating screen/shaker sieve machine/food grade stainless steel screen/sieve vibrating separator/sieves vibrating machine/wheat mill sieve/rotary screen supplie/extractos de hierbas centrfuga rotary screening machine/Screener vibrating/electric sieve vibrator/Tea powder Screening Machine/powder vibrating sieve machine/rotary screening/Wheat Flour Sieving With Vibro Sifter/vibrate screen mesh/separator sieve/flour sieve industrial/industrial rotary drum sieve/industrial sieves for flour/black fly soldier farming Screen vibrating machine/vibrating screening/vibrate screen classifier/circular vibrating screen/vibrating screen price/vibration screen frame/pakistan vibrating sieve machine/fabrication machine vibrating sieve/sieving machine powder/small sieving machine/ultrasonic classifying vibrating sieve/vibrating sieves separator machine/bean sprout vibrating separator
